Non-ambient Powder Diffraction in a Compact Footprint

axrd benchtop powder brochure

download pdf

The AXRD Theta-Theta brings non-ambient diffraction to your lab in a cost-effective, compact unit. This system provides a unique solution for high-temperature diffraction, with temperature stages from -190ºC to 2000ºC.

The AXRD Theta-Theta has been designed to handle larger samples or accommodate situations in which more room is needed for experimental stages, such as temperature stages or pressure cells. The FlexStage option makes mounting large samples easy, while the fully integrated cooling system keeps facility requirements to a minimum.


  • 200 mm goniometer radius
  • 1200 Watt x-ray system
  • Vertical theta-theta measurement geometry
  • High-speed photon-counting detector
  • Temperature stage options (-190ºC to 2000ºC)
  • Gas pressure stage option
  • FlexStage for mounting large samples
  • Sample exchanger
  • Compact footprint: 100 x 61 x 171 cm (W x D x H)
AXRD Theta-Theta powder diffractometert
Low Temp Chamber

Low-temperature chamber - TTK600

Compact Heating Stage

Compact heating stages - BTS 150 / BTS 500

Reactor Chamber

Reactor chamber -
XRK 900

High-temp oven chamber

High-temperature oven chamber - HTK 1200N

Variable Pressure Stage

Variable-pressure stage - PS30

LPD x-ray source

High-temperature strip heater chambers - HTK 16N / HTK 2000N


Large sample stage - FlexStage

Custom stage

Custom stages & holders
